Intel® LGA1700 12/13/14th Gen Socket Processor (Formerly Alder Lake-S, TDP 65W)
For additional compatible CPUs, please contact regional sales
CHIPSET
Intel® Q670E
MEMORY
2 x Intel® 12th/13th/14th CPU supports DDR5 4800MHz Dual Channel SO-DIMM, up to 96GB max
2 x Intel® 13th/14th CPU supports DDR5 5600MHz Dual Channel SO-DIMM, up to 64GB max
BIOS
AMI Flash ROM
WAKE ON LAN
Yes
WATCHDOG TIMER
255 Levels
SECURITY
TPM2.0
RTC BATTERY
Lithium Battery
OS SUPPORT
Windows® 11 (64bit)
Linux
POWER
POWER REQUIREMENT
1U FLEX 400W ATX PWR (4+24 pin)
MB
ATX Power Input (24pin ATX + 4pin 12V)
POWER ON MODE
ATX (Default) Mode
DISPLAY
GPU
Intel® UHD Graphics, shared memory
HDMI
1 x HDMI (Max Resolution: 1920 x 1080@60Hz)
LAN
ETHERNET
7 x RJ45 for Intel® i225-V 2.5GbE
1 x RJ45 for Intel® i225-LM 2.5GbE
SYSTEM I/O
REAR PANEL I/O
AC input CON
Power on/off SW
FRONT PANEL I/O
8 x RJ45
2 x USB 3.2(Gen.2)
2 x USB3.2 (Gen.1)
1 x RS-232
1 x HDMI
1 x Alarm LED
1 x Power LED
1 x Power Switch
STORAGE
SATA
2 x 2.5" SATA 6Gb/s internal drive bay (only Support 2.5" HDD with a hight ≤ 10mm)
EXPANSION
M.2
1 x M-key 2242/2280 (PCIe Gen.4×4 w/SATA interface)
1 x M-key 2280 (PCIe Gen.4×4 w/SATA interface) support NVMe
1 x E-Key 2230 (USB 2.0/PCIe x1) Support CNVi
1 x B-key 3042 (USB3.2 Gen.1/USB2.0/PCIe x1 interface) support 4G Module
