Model
|
– HBJC903I05-6412 (Default)
– HBJC903I05I-6412 (Wifi)
|
|
CPU/Chipset
|
– Intel® Elkhart Lake SoC Processor (J6412 , 4C/2.0GHz, TDP 10W)
|
|
BIOS
|
– AMI 128Mb Flash ROM
|
|
Memory
|
– 1* DDR4 3200MHz SO-DIMM up to 32GB
|
|
Network
|
– 6* Intel® i225-V 2.5GbE
|
|
Graphics
|
– Intel® HD Graphics, shared memory
– 1* HDMI (Max Resolution: 1920×1080@60Hz)
– Support Single Display
|
|
Storage
|
– 1* M.2 M-key (2242, SATA/PCIe Gen.3×2 interface) support NVMe
– 1* 2.5” SATAIII Device
|
|
Expansion
|
– 1* M.2 E-key (2230, USB2.0/PCIe Gen.3 x1 interface)
– 1* M.2 B-key (3042, USB3.1/PCIe Gen.3 x1 interface)
|
|
Rear Panel I/O
|
– 1* USB 3.1 (Gen.2)
– 1* USB 2.0
– 6* RJ45
– 1* Console RS232 (RJ45 TYPE)
– 3* COM (1* RS232/422/485, 2* RS232)
– 1* HDMI
– 1* Power LED, 1* HDD LED
– 1* Power Button
– 1* DC-in Jack (Lockable)
– 2* Antenna (Optional)
– 1* GND Hold
|
|
Front Panel I/O
|
– N/A
|
|
Internal Connector
|
– SIM Card Holder
|
|
Power Source
|
– MB | DC-in 12V
– Adapter | DC12V_60W
|
|
Compliance
|
– CE, FCC, RoHS, ErP Ready
|
|
Dimensions
|
– System: 200 (W) x 180 (D) x 59.5 (H) mm
– Box: 287 (W) x 122 (D) x 280 (H) mm
– Net Weight: 2.26KG
– Gross Weight: 3.26KG
|
|
Temperature
|
– Operating Temperature: -20 ~ 60° C
– Storage Temperature: -20 ~ 60° C
– Humidity: 10% ~ 90% RH @40°C (non-condensing)
|
|
OS Support
|
– Windows 10, Windows 11, Linux
|
|
Warranty
|
– 2 Year limited warranty
|
