| SYSTEM |
|
CPU
|
Intel® Celeron® Processor J Series (formerly Elkhart Lake)
|
|
CHIPSET
|
Intel® J6412 (TDP 10W)
|
|
SYSTEM MEMORY
|
1 x DDR4 3200/2933MHz up to 32GB
|
|
DISPLAY INTERFACE
|
1 x HDMI (Max Resolution | 2560×1600@60Hz)
|
|
STORAGE DEVICE
|
1 x M.2 M key (2242, SATA Interface)
1 x 2.5″ SATA 6Gb/s internal drive bay (hight ≦10mm)
|
|
ETHERNET
|
6 x Intel® 2.5 GbE LAN i225-V (or Intel® I226-V) LAN3/4/5/6 PoE LAN, Support IEEE 802.3af/at (Total Max 100W)
|
|
Front I/O
|
—
|
|
Rear I/O
|
1 x Phoenix terminal block System (12V DC in)
1 x HDMI (Max Resolution | 2560×1600@60Hz)
4 x COM (COM1: RS232-RJ45, COM2: RS232/422/485, COM3/4: RS232)
1 x Power Button
1 x GND Hold
1 x Power LED
1 x HDD LED
2 x USB3.2 Gen.1
6 x RJ45
1 x Phoenix terminal block for PoE (9~36V DC in)
|
|
EXPANSION
|
—
|
|
INDICATOR
|
1 x Power LED
1 x HDD LED
|
|
OS SUPPORT
|
Windows® 10
Windows® 11
Linux
|
| POWER SUPPLY |
|
POWER REQUIREMENT
|
MB | 12V DC-in
POE: 9~36V DC-in for PoE
Adapter | AC100~240V / DC12V_7.5A_90W
|
| MECHANICAL |
|
MOUNTING
|
Desktop, Wallmount
|
|
DIMENSIONS (W x H x D)
|
200.0(W) x 180.4 (D) x 59.5 (H) mm (6.0″ x 5.41″ x 1.78″)
|
|
GROSS WEIGHT
|
—
|
|
NET WEIGHT
|
—
|
| ENVIRONMENT & CERTIFICATION |
|
OPERATING TEMPERATURE
|
-10°C ~ 50°C (14°F ~122°F)
(Under the condition of using M.2 interface SSD)
|
|
STORAGE TEMPERATURE
|
-20°C ~ 60°C (-4°F ~140°F)
|
|
OPERATING HUMIDITY
|
10 ~ 90% @ 40°C, non-condensing
|
|
ANTI-VIBRATION
|
—
|
|
ANTI-SHOCK
|
—
|
|
CERTIFICATION
|
CE/FCC Class A , LVD
|
